Available Versions & Licensing
The ntopng software comes in four versions: Community, Professional, Enterprise M, Enterprise L, and Enterprise L Bundle. Each version unlocks additional features with respect to the smaller one.
The full list of features and differences between versions is available in the ntopng Product Page.
ntopng Community
The Community version is free to use and open source. The full source code can be found on Github.
ntopng Professional
The Professional version offers some extra features with respect to the Community, which are particularly useful for SMEs, including graphical reports, traffic profiles and LDAP authentication.
ntopng Enterprise M
The Enterprise M version offers some extra features with respect to the Professional version, which are particularly useful for large organizations, including SNMP support, advanced alerts management.
ntopng Enterprise L
The Enterprise L version offers some extra features with respect to the Enterprise M version, including fast ClickHouse export, historical data explorer and analysis, Identity Management (the ability to correlate users to traffic).
ntopng Enterprise L Bundle
The Enterprise L Bundle unlocks ntopng Enterprise L, nProbe Pro (Flow Collection), and n2disk 1 Gbit (Continuous Recording).
Warning
ntopng and nProbe must be on the same machine to have them unlocked with the ntopng Enterprise L Bundle license. The bundle license must be placed under /etc/ntopng/ntopng.license.
Licensing
The Community edition does not need any license. Professional and Enterprise versions require a license. ntopng automatically switches to one of these four versions, depending on the presence of a license.
License is per-server and is released according to the EULA (End User License Agreement). Each license is perpetual (i.e. it does not expire) and it allows to install updates for one year since purchase/license issue. This means that a license generated on 1/1/2021 will be able to activate new versions of the software until 12/31/2021. If you want to install new versions of the software release after that date, you need to renew the maintenance or avoid further updating the software. For source-based ntopng you can refer to the GPL-v3 License.
ntopng licenses are generated using the orderId and email you provided when the license has been purchased on https://shop.ntop.org/.
Once the license has been generated, it can be applied to ntopng simply by visiting page “Settings”->”License” of the web GUI and pasting the license key in the license form.
Alternatively, the license key can be placed in a one-line file
ntopng.license:
On Linux, the file must be placed in
/etc/ntopng.licenseOn Windows, the file must be placed in
Program Files/ntopng/ntopng.license
Note
An ntopng restart is recommended once the license has been applied to make sure all the new functionalities will be unlocked.
Purchasing a License
The first step is to purchase a license. Licenses can be purchased online at https://shop.ntop.org. For bulk purchases, reseller discounts, or any other special requirement related to the purchase of licenses you can contact ntop directly. Once the purchase has been completed successfully, you will receive an Order Id.
The Order Id
The Order Id is a numeric identifier associated to the purchase. Along with the Order Id you’ll also find the email indicated during the purchase procedure. Both Order Id and the email are necessary to generate the license key.
Generating the License Key
License keys are generated at https://shop.ntop.org/mkntopng/. To generate the license key, you need:
The Order Id received after the purchase and the email indicated during the purchase procedure (see Purchasing a License).
The System Id, that is, an identifier associated to the host running ntopng
The ntopng version, that is, a string representing the version of the installed ntopng (e.g., 5.1.210819).
Note
The System Id and the version can only be obtained after ntopng has been installed successfully. If you have not yet installed it, follow the installation procedure indicated at https://packages.ntop.org/ before moving forward with the license key generation.
The System Id and the version can be always obtained from the ntopng UI, page “Help -> About”
System Id and version from the UI
On Linux, FreeBSD and other unix-based systems, the System Id and the version can also be obtained from the command line simply with an ntopng --version
$ ntopng --version
Version: 5.1.210819 [Enterprise/Professional build]
GIT rev: dev:065742705143bd1af06cf99fb2f35505ee349bb3:20210819
Pro rev: r4187
Built on: Ubuntu 16.04.7 LTS
System Id: LA2D7D2FB9206AAF2--UA2D7D2FBDDCCD490--OL
Platform: x86_64
Edition: Enterprise L (Bundle)
License Type: Time-Limited [Empty license file]
Validity: Until Thu Aug 19 18:23:03 2021
On Windows, System Id and the version can be printed from the command interpreter with a ntopng.exe /c --version inside the ntopng installation directory C:Program Filesntopng.
Generating The Key
To generate the license visit https://shop.ntop.org/mkntopng/ and fill the form using all the information indicated above.
Warning
You must also pick the right version from the dropdown ntopng Edition:. Make sure this version matches with the version you’ve purchased or the license generation will fail.
Installing The Key
Upon successful generation, the license key will be printed in the browser. At this point you have two options:
You can copy the license key in a plain text file /etc/ntopng.license, e.g.,
# echo "XJQ6U04QIW2ixxzNMfGnWibAySvd8Rd3K4qxymrZNT3DoR0m1K6Ybx1nnG1Y1n+7O4znPE4Zroy+A5EZZfu/i0UzrOhly/HNUgNju+RTP6d/zAvMTs04ZtIG9/BjalrrOfHzw0bU3uTm0z1F+S5N6IFUP6cXzoWP+yrpGmPjzmQHGa5kSw5IJw6YjmPvAgGLHsKn+u2KoA6xP7c4eZ7YGJ/S6MTmYtLFOBse4qoaViSC30RBu54QVG4Zafz4qwhMEnT+hijwbkWJfjZBRzl3eLE05HclnkRWibuYJqKG6c9NRExF0u6a3+P/+ouB7PcczDf8G4O22MWgr2cTNjsmRA==" > /etc/ntopng.license
Alternatively on selected platforms (e.g. Windows), you can paste the license key straight into the ntopng UI, page “Settings -> License”
Installing the ntopng License Key
This said it is recommended to place the license key in the plain text file.
Note
A restart of ntopng is required after license installation to make sure all the licensed features will be properly unlocked.
Example
Let’s say that we’ve purchased an ntopng Enterprise L license for:
$ ntopng --version
Version: 5.1.210819 [Enterprise/Professional build]
[...]
System Id: LA2D7D2FB9206AAF2--UA2D7D2FBDDCCD490--OL
The Order Id received after the purchase is 1621231231 and the email indicated during the purchase procedure is info@ntop.org.
The form at https://shop.ntop.org/mkntopng/ will be filled as follow
License Generation Example
Upon successful generation, the license key will be printed in the browser:
The Obtained License Key
At this point the license can be installed as described above or simply by following the instructions indicated in the resulting page.
Using the License Manager
In addition to the standard licenses described above, ntopng can use the license manager (LM). Please refer to https://www.ntop.org/guides/nprobe/introduction.html#using-the-license-manager for details about the LM.
In order to use the LM simply do `ntopng --license-mgr <licensemgr>.conf <other ntopng options>`.
Below you can find an example of license manager configuration file for ntopng:
LICENSE_MANAGER=127.0.0.1:9999
#
# Unique instance name
#
INSTANCE_NAME=dummy ntopng instance
#
# User authentication token
#
AUTH_TOKEN=fjfgsfgsj
#
# nprobe ntopng
#
PRODUCT_FAMILY=ntopng
#
# pro enterprise_s enterprise_m enterprise_l
#
PRODUCT_EDITION=enterprise_m
where
LICENSE_MANAGER is the IP and port of the host where the LM is running.
INSTANCE_NAME is a string used to indetity this specific instance
AUTH_TOKEN is a token that the LM can use to prevent issuing valid licenses for unknown AUTH_TOKEN. Its value must be configured in the LM.
PRODUCT_FAMILY and PRODUCT_EDITION define what license the ntop application will as the LM when contacting it.
Licenses on a Container
An article that explain everything in details on how to deploy a license inside a container can be found here: Deploying Licenses inside Conteainers
Models Comparison Table
Feature |
Community |
Pro |
M |
L |
XL |
XXL |
|---|---|---|---|---|---|---|
Monitor Remote Hosts using active monitoring (ICMP, HTTP/S, Throughput, SpeedTest) |
✓ |
✓ |
✓ |
✓ |
✓ |
✓ |
Monitor the system, machine on which ntopng is running (CPU, RAM, Disk, etc.) |
✓ |
✓ |
✓ |
✓ |
✓ |
✓ |
Identify application protocols (Facebook, Youtube, BitTorrent, etc) in the network |
✓ |
✓ |
✓ |
✓ |
✓ |
✓ |
Record and Visualize hosts’ historical application protocols usage (timeseries) |
✓ |
✓ |
✓ |
✓ |
✓ |
✓ |
Group hosts by VLAN, Operating System, Country, and Autonomous Systems |
✓ |
✓ |
✓ |
✓ |
✓ |
✓ |
Get a geographic map of your network communications with the rest of the world |
✓ |
✓ |
✓ |
✓ |
✓ |
✓ |
Discover the devices connected to your Local Network (Network Discovery) |
✓ |
✓ |
✓ |
✓ |
✓ |
✓ |
Identify top talkers (senders and receivers) hosts with minute resolution |
✓ |
✓ |
✓ |
✓ |
✓ |
✓ |
Visualise the top HTTP sites contacted by an host |
✓ |
✓ |
✓ |
✓ |
✓ |
✓ |
Export expired flows information to database, possibly augmented with nProbe data ** |
✗ |
✓ |
✓ |
✓ |
✓ |
✓ |
Generate alerts (for Flows, Hosts, Interfaces, …) when certain conditions are detected (Threshold Crossed, Suspicious Behaviour, …) |
✓ |
✓ |
✓ |
✓ |
✓ |
✓ |
Navigate through the alerts, from the GUI, generated by ntopng to find the problem |
✓ |
✓ |
✓ |
✓ |
✓ |
✓ |
Get alerts notifications as Email, Discord, Telegram, WebHook, Slack, Syslog messages or execute Shell Scripts |
✓ |
✓ |
✓ |
✓ |
✓ |
✓ |
Split, merge, and visualize VLAN based traffic |
✓ |
✓ |
✓ |
✓ |
✓ |
✓ |
CollCollect data from nProbe to treat remote nProbe-monitored interfaces and flow exporter devices (for example routers and switches) as if they were localect data from remote nProbe-monitored interfaces and flow exporters |
✓ |
✓ |
✓ |
✓ |
✓ |
✓ |
Split, merge, and visualize data collected from nProbe |
✓ |
✓ |
✓ |
✓ |
✓ |
✓ |
Group local hosts into logical sets of IP and MAC addresses known as host pools |
✓ |
✓ |
✓ |
✓ |
✓ |
✓ |
Add/edit application protocols to ntopng (if a protocol file is configured) and edit protocol categories |
✗ |
✓ |
✓ |
✓ |
✓ |
✓ |
Aggregate multiple interfaces traffic in a single view |
✗ |
✓ |
✓ |
✓ |
✓ |
✓ |
Limit or block hosts’ traffic with customized per-application policies * |
✗ |
✗ |
✓ |
✓ |
✓ |
✓ |
Integrate ntopng login with LDAP authentication servers * ** |
✗ |
✓ |
✓ |
✓ |
✓ |
✓ |
Send alerts to Elasticsearch, to MS Teams or to Fail2Ban |
✗ |
✓ |
✓ |
✓ |
✓ |
✓ |
Have access to other ntopng Checks (Alerts) |
✗ |
✓ |
✓ |
✓ |
✓ |
✓ |
Add the possibility to create the Network Matrix timeseries (gives the possibility to check traffic between Local Networks) |
✗ |
✓ |
✓ |
✓ |
✓ |
✓ |
Visualize and historicise other ntopng data (Interface Score Anomalies, Top Talkers, …) |
✗ |
✗ |
✓ |
✓ |
✓ |
✓ |
Graphical reports with top hosts, application protocols, countries, networks, and autonomous systems within any configurable time frame |
✗ |
✗ |
✓ |
✓ |
✓ |
✓ |
Automatic (periodic) graphical reports |
✗ |
✗ |
✗ |
✓ |
✓ |
✓ |
Graphical reports editor to build custom report templates |
✗ |
✗ |
✗ |
✗ |
✓ |
✓ |
Query SNMP devices data, such as port status, traffic and and MAC address information |
✗ |
✗ |
✓ |
✓ |
✓ |
✓ |
Get total traffic and activity reports for any given host, network, or interface |
✗ |
✗ |
✓ |
✓ |
✓ |
✓ |
Identify attackers and victims through an alerts dashboard in realtime and in the past |
✗ |
✗ |
✓ |
✓ |
✓ |
✓ |
Visualize host pools’ historical applications protocols usage |
✗ |
✗ |
✓ |
✓ |
✓ |
✓ |
Explore and filter flow alerts in the past |
✗ |
✗ |
✓ |
✓ |
✓ |
✓ |
Trigger alerts when SNMP unexpected behavior shows up |
✗ |
✗ |
✓ |
✓ |
✓ |
✓ |
Have access to other ntopng Checks (Alerts, such as SNMP Alerts) |
✗ |
✗ |
✓ |
✓ |
✓ |
✓ |
Visualize and historicise SNMP per-device-port traffic |
✗ |
✗ |
✓ |
✓ |
✓ |
✓ |
Visualize and historicise NetFlow/sFlow devices data |
✗ |
✗ |
✓ |
✓ |
✓ |
✓ |
Aggregate and Analyze Long-term flow data |
✗ |
✗ |
✓ |
✓ |
✓ |
✓ |
Apply per-protocol daily traffic and time quotas to your clients * |
✗ |
✗ |
✓ |
✓ |
✓ |
✓ |
High performance flow export to ClickHouse and explorer (both aggregated data explorer and historical flow explorer) * |
✗ |
✗ |
✓ |
✓ |
✓ |
✓ |
Custom Interface Disaggregation *** |
✗ |
✗ |
✓ |
✓ |
✓ |
✓ |
Monitor other ntopng instances (Infrastructure Monitoring) |
✗ |
✗ |
✗ |
✓ |
✓ |
✓ |
Hosts Map (find the hosts outliers) |
✗ |
✗ |
✓ |
✓ |
✓ |
✓ |
Service / Periodicity Maps |
✗ |
✗ |
✗ |
✓ |
✓ |
✓ |
Identity Management with Firewalls and Active Directory |
✗ |
✗ |
✗ |
✓ |
✓ |
✓ |
Have access to all Behavioural Checks |
✗ |
✗ |
✗ |
✓ |
✓ |
✓ |
Native nTap Support |
✗ |
✗ |
✗ |
✓ |
✓ |
✓ |
Kafka Support |
✗ |
✗ |
✗ |
✓ |
✓ |
✓ |
OT/SCADA: IEC 60870-5-104 Traffic Analysis |
✓ |
✓ |
✓ |
✓ |
✓ |
✓ |
OT/SCADA: ModbusTCP Traffic Analysis |
✗ |
✗ |
✗ |
✓ |
✓ |
✓ |
Continuous Recording license Included (n2disk 1Gbit) ** *** |
✗ |
✗ |
✗ |
Bundle L |
Bundle XL |
✗ |
Smart Recording license Included (n2disk 1Gbit) ** *** |
✗ |
✗ |
✗ |
✗ |
Bundle XL |
✗ |
Flow Collection license Included (nProbe Pro) *** |
✗ |
✗ |
✗ |
Bundle L |
✗ |
✗ |
Flow Collection license Included (nProbe Enterprise S) *** |
✗ |
✗ |
✗ |
✗ |
Bundle XL |
✗ |
Maximum Number of Monitored (Local) Hosts (suggested) |
256 |
256 |
1K |
4K |
32K |
128K |
Maximum Number of Monitored Flows (suggested) |
128K |
1M |
4M |
8M |
16M |
32M |
Max Number of Host Pools |
3 |
3 |
128 |
128 |
128 |
128 |
Max Number of Host Pool Members (per Pool) |
8 |
8 |
Unlimited |
Unlimited |
Unlimited |
Unlimited |
Maximum Number of Monitored Interfaces (-i) |
8 |
8 |
16 |
32 |
64 |
64 |
Mark and historicize traffic with user-defined traffic profiles to match hosts, ports and applications using the BPF syntax (number of profiles) [total/per ntopng] |
16 |
128 |
128 |
128 |
128 |
|
Configurable SNMP Devices (device number) [total/per ntopng] |
16 |
32 |
128 |
512 |
||
Max Number of Flow Exporters (e.g. NetFlow router) [total/per ntopng] |
4 |
16 |
128 |
256 |
512 |
|
Flow Exporters/Interfaces combinations [total/per ntopng] |
128 |
256 |
512 |
2K |
8K |
✓ = Feature available, ✗ = Feature NOT available
* Feature not available on Windows
** Feature not available on FreeBSD / OPNsense / pfSense
*** Read more about the software bundled with the Bundle edition in the FAQ
